| Specifications
|
|---|
|
Date of Introduction |
1969 |
|
Proliferation |
At least 1 country |
|
Description |
|
|
Crew |
2 |
|
Troop Capacity |
5 passengers (+1) |
|
Combat Weight (mt) |
13.3 |
|
Chassis Length Overall (m) |
6.74 |
|
Height Overall (m) |
2.15 |
|
Width Overall (m) |
2.94 |
|
Ground Pressure (kg/cm 2 ) |
0.57 |
|
Automotive Performance |
|
|
Engine Type |
240-hp Diesel |
|
Cruising Range (km) |
600 |
|
Speed (km/h) |
|
|
Max Road |
65 |
|
Max Off-Road |
40-45 |
|
Average Cross-Country |
INA |
|
Max Swim |
7 |
|
Fording Depth (m) |
Amphibious |
|
Radio |
R-123M |
|
Protection |
|
|
Armor, Turret Front (mm) |
23 or Antibullet |
|
Active Protective System |
N/A |
|
Mineclearing Equipment |
N/A |
|
Self-Entrenching Blade |
N/A |
|
NBC Protection System |
Collective |
|
Smoke Equipment |
VEESS |
|
ARMAMENT |
|
|
Main Armament |
|
|
Caliber, Type, Name |
73-mm smoothbore gun, 2A28/Grom |
|
Rate of Fire(rd/min) |
7-8 |
|
Loader Type |
Autoloader |
|
Ready/Stowed Rounds |
40 / 0 |
|
Elevation (°) |
-4/ +33 |
|
Fire on Move |
Yes, but only 10 km/h or less (est) |
|
Auxiliary Weapons |
|
|
Caliber, Type, Name |
7.62-mm (7.62x 54R) machinegun, PKT |
|
Mount Type |
Coax |
|
Maximum Aimed Range (m) |
1,300 |
|
Max Effective Range (m) |
|
|
Day |
1,000/400-500 on the move |
|
Fire on Move |
Yes |
|
Rate of Fire (rd/min) |
250 practical / 650 cyclic, 2-10 round bursts |
|
Caliber, Type, Name |
7.62-mm machinegun, PKT |
|
Mount Type |
Bow (ball-mounted) |
|
Maximum Aimed Range (m) |
1,000 |
|
Max Effective Range (m) |
|
|
Day |
1,000/ 400-500 on the move |
|
Night |
N/A |
|
Fire on Move |
Yes |
|
Rate of Fire (rd/min) |
250 practical / 650 cyclic, 2-10 round bursts |
|
ATGM Launcher |
|
|
Name |
9P111 |
|
Launch Method |
Rail-launched |
|
Guidance |
MCLOS |
|
Command Link |
Wire |
|
Launcher Dismountable |
Yes |
|
Firing Ports |
1 on each side, 1 in left rear door |
|
FIRE CONTROL |
|
|
FCS Name |
INA |
|
Main Gun Stabilization |
N/A |
|
Rangefinder |
Stadiametric |
|
Infrared Searchlight |
Yes |
|
Sights w/Magnification |
|
|
Gunner |
|
|
Day |
1PN22M1, 8x |
|
Field of View (°) |
15 |
|
Acquisition Range (m) |
|
|
Night |
1PN22M1, 6.7x |
|
Field of View (°) |
6 |
|
Acquisition Range (m) |
800-1,000, based on light |
|
Commander Fire Main Gun |
No |
|
MAIN ARMAMENT AMMUNITION |
|
|
Caliber, Type, Name |
|
|
73-mm HEAT-FS, PG-9 |
|
|
Maximum Aimed Range (m) |
1,300 |
|
Max Effective Range (m) |
|
|
Day |
800, but 600 or less on the move |
|
Night |
800 |
|
Tactical AA Range |
INA |
|
Armor Penetration (mm) |
335 (RHA) |
|
73-mm HEAT-FS, NFI |
|
|
Maximum Aimed Range (m) |
1,300 |
|
Max Effective Range (m) |
|
|
Day |
1,000, but 600 or less on the move |
|
Night |
800-1,000 |
|
Tactical AA Range |
INA |
|
Armor Penetration (mm) |
400 (RHA) |
|
73-mm HE, OG-9 |
|
|
Maximum Aimed Range (m) |
1,300, 600 or less on the move |
|
Max Effective Range (m) |
|
|
Day |
1,300, but 600 or less on the move |
|
Night |
800-1,000 |
|
Tactical AA Range |
INA |
|
Armor penetration (mm) |
INA |
|
73-mm HE, OG-9M1 |
|
|
Maximum Aimed Range (m) |
4,500 |
|
Max Effective Range (m) |
|
|
Day |
1,300, but 600 or less on the move |
|
Night |
800-1,000 |
|
Tactical AA Range |
INA |
|
Armor Penetration (mm) |
INA |
|
Other Ammunition Types |
OG-9M |
|
Antitank Guided Missiles |
|
|
Name |
AT-3, -3A, -B |
|
Warhead Type |
Tandem HEAT |
|
Armor Penetration (mm) |
410 RHA |
|
Range (m) |
3,000 |
|
Name |
AT-3C |
|
Warhead Type |
Tandem HEAT |
|
Armor Penetration (mm) |
520 RHA |
|
Range (m) |
3,000 |
|
Name |
AT-3C Imp/ Polk (Slovenian) |
|
Warhead Type |
Precursor with HEAT |
|
Armor Penetration (mm) |
580 RHA |
|
Range (m) |
3,000 |
|
Name |
Malyutka-2 (Russian) |
|
Warhead Type |
Tandem HEAT |
|
Armor Penetration (mm) |
800 RHA |
|
Range (m) |
3,000 |
|
Name |
Malyutka HE (Russian) |
|
Warhead Type |
Frag-HE |
|
Armor Penetration (mm) |
N/A |
|
Range (m) |
3,000
|
