| Specifications
|
|---|
|
Alternative Designations | N/A |
|
Date of Introduction | 1992 |
|
Proliferation | At least 1 country |
|
Description | |
|
Crew | 3 |
|
Troop Capacity | 4 (+3) passengers |
|
Combat Weight (mt) | 12.9 |
|
Length Overall (m) | 6.00 |
|
Height Overall (m) | 2.25 |
|
Width Overall (m) | 3.13 |
|
Ground Pressure (kg/cm 2 ) | 0.32 (wide track) / .48 (standard track) |
|
Automotive Performance | |
|
Engine Type | 450-hp Diesel |
|
Cruising Range (km) | 500 |
|
Speed (km/h) | |
|
Max Road | 70 |
|
Max Off-Road | 45 |
|
Average Cross-Country | INA |
|
Max Swim | 10 |
|
Fording Depth (m) | Amphibious |
|
Radio | R-173 |
|
Protection | |
|
Armor, Turret Front (mm) | "Antibullet" (7.62) |
|
Applique Armor (mm) | N/A |
|
Explosive Reactive Armor (mm) | Available |
|
Active Protective System | N/A |
|
Mineclearing Equipment | KMT-8 plow or -10 roller |
|
Self-Entrenching Blade | N/A |
|
NBC Protection System | Collective |
|
Smoke Equipment | Smoke grenade launchers, 3 x each side of turret
Vehicle engine exhaust smoke system (VEESS) |
|
ARMAMENT | |
|
Main Armament | |
|
Caliber, Type, Name | 30-mm automatic gun, 2A42 |
|
Rate of Fire (rd/min) | 550 cyclic in bursts/ 200-300 practical |
|
Loader Type | Dual-belt feed |
|
Ready/Stowed Rounds | 500/ 360 |
|
Elevation (°) | -5 to +74 |
|
Fire on Move | Yes |
|
Auxiliary Weapons | |
|
Caliber, Type, Name | 30-mm automatic grenade launcher, AG-17 |
|
Mount Type | Bow left side |
|
Maximum Aimed Range (m) | 1,700 |
|
Max Effective Range (m) | |
|
Day | 1,200 |
|
Night | N/A |
|
Fire on Move | Yes |
|
Rate of Fire (rd/min) | 60-100 practical in short (< 5 rds) or long
(6-10 rd) bursts. |
|
Caliber, Type, Name | 7.62-mm (7.62 x 54R) machinegun, PKT |
|
Mount Type | Turret coax |
|
Maximum Aimed Range (m) | 2,000 |
|
Max Effective Range (m) | |
|
Day | 1,000 |
|
Night | 1,000 |
|
Fire on Move | Yes |
|
Rate of Fire (rd/min) | 250 practical / 650 cyclic, 2-10 round bursts |
|
Caliber, Type, Name | 5.45-mm light machinegun, RPK-74 |
|
Mount Type | Bow right side |
|
Maximum Aimed Range (m) | 1,000 |
|
Max Effective Range (m) | |
|
Day | 800 |
|
Night | INA |
|
Fire on Move | Yes |
|
Rate of Fire (rd/min) | 150 automatic/ 50 semiautomatic |
|
ATGM Launcher | |
|
Name | 9P135 |
|
Launch Method | Tube-launched |
|
Guidance | SACLOS |
|
Command Link | Wire |
|
Launcher Dismountable | Yes |
|
FIRE CONTROL | |
|
FCS Name | INA |
|
Main Gun Stabilization | 2-plane |
|
Rangefinder | Laser |
|
Infrared Searchlight | Yes |
|
Sights w/Magnification | |
|
Gunner | |
|
Day | BPK-2-42 |
|
Field of View (°) | 8 |
|
Acquisition Range (m) | INA |
|
Night | BPK-2-42 II/IR |
|
Field of View (°) | INA |
|
Acquisition Range (m) | INA |
|
Commander Fire Main Gun | No |
|
MAIN ARMAMENT AMMUNITION | |
|
Caliber, Type, Name | 30-mm AP-T |
|
Maximum Aimed Range (m) | 2,500 |
|
Max Effective Range (m) | |
|
Day | 1,500 |
|
Night | INA |
|
Tactical AA Range | 4,000 |
|
Armor Penetration (mm) | 18 (RHA) at 1,500m |
|
30-mm APDS | |
|
Maximum Aimed Range (m) | 2,500 |
|
Max Effective Range (m) | |
|
Day | 2,000 |
|
Night | INA |
|
Tactical AA Range | 4,000 |
|
Armor Penetration (mm) | 25 (RHA) at 1,500m |
|
30-mm APFSDS-T M929 |
|
Maximum Aimed Range (m) | 2,500 |
|
Max Effective Range (m) | |
|
Day | 2,000+ |
|
Night | INA |
|
Tactical AA Range | 4,000 |
|
Armor penetration (mm) | 55 (RHA) at 1,000m, 45 at 2,000m |
|
30-mm Frag-HE | |
|
Maximum Aimed Range (m) | 4,000 |
|
Max Effective Range (m) | |
|
Day | 4,000 |
|
Night | INA |
|
Tactical AA Range | 4,000 |
|
Armor Penetration (mm) | INA |
|
Other Ammunition Types | 30-mm HEI-T |
|
Antitank Guided Missiles | |
|
Name | AT-5B/Konkurs-M |
|
Warhead Type | Tandem shaped charge (HEAT) |
|
Armor Penetration (mm) | 925 (RHA) |
|
Range (m) | 4,000 |
|
Name | AT-5/Spandrel |
|
Warhead Type | Shaped charge (HEAT) |
|
Armor Penetration (mm) | 650 (RHA) |
|
Range (m) | 4,000
|
