| Specifications
|
|---|
|
Alternative Designations | 152-mm 2S3M Akatsiya |
|
Date of Introduction | 1973 |
|
Proliferation | At least 8 countries |
|
Description | |
|
Crew | 4 |
|
Platform (chassis) | Modified SA-4 Ganef |
|
Combat Weight (mt) | 27.5 |
|
Chassis Length Overall (m) | 7.75 |
|
Height Overall (m) | 3.13 |
|
Width Overall (m) | 3.21 |
|
Automotive Performance | |
|
Engine Type | 520-hpV-59 V-12 multi-fuel diesel |
|
Cruising Range (km) | 450 km |
|
Speed (km/h) | |
|
Max Road | 60 |
|
Max Off-Road | 25 |
|
Cross-Country | INA |
|
Max Swim | N/A |
|
Fording Depth (m) | 1.00 |
|
Emplacement Time (min) | 3 |
|
Displacement Time (min) | 3 |
|
Radio | R-123M |
|
Protection | |
|
Armor, Turret (mm) | 20 |
|
Armor Turret Top (mm) | 15 |
|
Armor Hull (mm) | INA |
|
Self-Entrenching Blade | Yes |
|
NBC Protection System | Yes |
|
Smoke Equipment | No |
|
ARMAMENT | |
|
Main Armament | |
|
Caliber, Type, Name | 152-mm, 2A33 |
|
Barrel Length (cal) | 34 |
|
Rate of Fire (rpm) | |
|
Burst | 4 |
|
Normal | 3 |
|
Sustained | 1 |
|
Fire from Ground | INA |
|
Loader Type | Semiautomatic |
|
Breech Type | Vertical sliding wedge |
|
Muzzle Brake Type | Double baffle |
|
Traverse | (°) |
|
Left | 360 |
|
Right | 360 |
|
Total | 360 |
|
Elevation (°) (-/+) | -4/+60° |
|
Auxiliary Weapon | |
|
Caliber, Type, Name | 7.62-mm machinegun PKT |
|
Mount Type | Bow (ball-mounted) |
|
Direct Fire Range (m) | 1000 |
|
Max Effective Range (m)` | |
|
Day | 1000 /400-500 on the move |
|
Night | 800 |
|
Fire on Move | Yes |
|
Rate of Fire (rpm) | 650 (cyclic) |
|
FIRE CONTROL | |
|
Indirect Fire | PG-4 Panoramic Telescope (PANTEL) |
|
Direct Fire | OP 5-38 |
|
Collimator | K-1 |
|
Gun Display Unit | None |
|
Fire Control Computer | None |
|
VARIANTS | |
|
2S3M1 | Upgrade of 2S3M |
|
MAIN ARMAMENT AMMUNITION | |
|
Caliber, Type, Name | |
|
152-mm Frag-HE, OF32 | |
|
Indirect Fire Range (m) | |
|
Minimum Range | 4600 |
|
Maximum Range | 17,400 |
|
Complete Projectile Weight (kg) | 43.56 (OF25) |
|
Muzzle Velocity | 655 m/s |
|
Fuze Type | V-90 PD |
|
152-mm, HEAT, BP-540 | |
|
Direct Fire Range (m) | |
|
Minimum Range | 0 |
|
Maximum Range | 1000 |
|
Armor Penetration (mm) | INA |
|
Complete Projectile Weight (kg) | 27.00 |
|
Muzzle Velocity | 655 m/s |
|
Fuze Type | GPV-3 PD
152-mm Frag-HE, OF-96 |
|
Indirect Fire Range (m) | |
|
Minimum Range | INA |
|
Maximum Range | 24,400 |
|
Complete Projectile Weight (kg) | 43.56 (OF-64) |
|
Muzzle Velocity | INA |
|
Fuze Type | PD |
|
Other Ammunition Types | DPICM, DPICM-BB, Incendiary,
Chemical, Flechette, Semi-active laser-guided Krasnopol-M Frag-HE
|
