| Specifications
|
|---|
|
Alternative Designations | 122-mm 2S1 Gvozdika |
|
Date of Introduction | 1974 |
|
Proliferation | At least 12 countries |
|
Description | |
|
Crew | 4 (section of 6 with 2 in ammo carrier) |
|
Platform (chassis) | MT-LBu |
|
Combat Weight (mt) | 15.7 |
|
Chassis Length Overall (m) | 7.26 |
|
Height Overall (m) | 2.72 |
|
Width Overall (m) | 2.85 |
|
Automotive Performance | |
|
Engine Type | V-8, 300 hp, Diesel |
|
Cruising Range (km) | 500 km |
|
Speed (km/h) | |
|
Max Road | 60 |
|
Max Off-Road | 30 |
|
Cross-Country | INA |
|
Max Swim | 4.5 |
|
Fording Depths (m) | Amphibious |
|
Emplacement Time (min) | 2 |
|
Displacement Time (min) | 1 |
|
Radio | R-123M |
|
Protection | |
|
Armor, Turret (mm) | 20 |
|
Armor Turret Top (mm) | 10 |
|
Armor Hull (mm) | 15 |
|
Self-Entrenching Blade | No |
|
NBC Protection System | Yes |
|
Smoke Equipment | No |
|
ARMAMENT | |
|
Main Armament | |
|
Caliber, Type, Name | 122-mm, canon, 2A31 |
|
Barrel Length (cal) | 36 |
|
Rate of Fire (rpm) | |
|
Burst | 5 |
|
Normal | 4 |
|
Sustained | 1-2 |
|
Fire from Ground | INA |
|
Loader Type | Semi-automatic |
|
Breech Type | Horizontal sliding wedge |
|
Muzzle Brake Type | Double baffle |
|
Traverse | (°) |
|
Left | 360 |
|
Right | 360 |
|
Total | 360 |
|
Elevation (°) (-/+) | -3/+70° |
|
FIRE CONTROL | |
|
Indirect Fire | PG-2 Panoramic Telescope (PANTEL) |
|
Direct Fire | OP 5-37 |
|
Collimator | K-1 |
|
Gun Display Unit | None |
|
Fire Control Computer | None |
|
VARIANTS | None |
|
MAIN ARMAMENT AMMUNITION | |
|
Caliber, Type, Name | |
|
122-mm Frag-HE, OF-81 | |
|
Indirect Fire Range (m) | |
|
Minimum Range | 1000 |
|
Maximum Range | 15,300 |
|
Complete Projectile Weight (kg) | 21.76 (OF-56) |
|
Muzzle Velocity | 680 m/s |
|
Fuze Type | RGM-2 PD |
|
122-mm, HEAT-FS | |
|
Direct Fire Range (m) | |
|
Minimum Range | 0 |
|
Maximum Range | 1000 |
|
Armor Penetration (mm) | 460 (@ 0° obliquity any range) |
|
Complete Projectile Weight (kg) | 21.58 |
|
Muzzle Velocity | 740 m/s |
|
Fuze Type | GPV-2 PIBD |
|
122-mm Frag-HE Rocket Assisted | |
|
Indirect Fire Range (m) | |
|
Minimum Range | INA |
|
Maximum Range | 21,900 |
|
Complete Projectile Weight (kg) | 21.76 (3OF-56) |
|
Muzzle Velocity | INA |
|
Fuze Type | PD |
|
Other Ammunition Types | Incendiary, Chemical, Flechette,
Expendable Jammer, Semi-active laser-guided Kitolov-2M Frag-HE
|
