K55 (155mm Self Propelled Howitzer)
| Field Artillery Ammunition Support Vehicle | |
|---|---|
| General | |
| Combat Weight | 26.5 ton |
| Length | 6.71 m |
| Width | 3.15 m |
| Height | 3.40 m |
| Engine | |
| Type/Model | 8V71T, Liquid Cooled | Horsepower(Gross) | 405 HP |
| Transmission | |
| Model | XGT-411-2A |
| Auxiliary Power Unit | 19.5. HP, Diesel |
| Performance | |
| Speed | |
| High Speed | 56.3 km/h |
| Reverse Speed | 11.2 km/h |
| Ground Clearance | 0.47 m |
| Gradient | 60% |
| Side Slope | 40% |
| Vertical Obstacle | 0.64 m |
| Trench | 1.83 m |
| Crusing Range | 360 km |
| Ammunition Load | |
| Ammunition | 110 rounds |
| Charge | 116 rounds |
| Fuse | 132 rounds |
| Loading Capability | |
| within 60 min at daytime | |
| within 90 min at night | |
| 6 rounds/min | |
|
