Type-14 105mm Anti-Aircraft Artillery

Type-4 75mm Anti-Aircraft ArtilleryThe Model 14 (1925) 105-mm antiaircraft gun was the heaviest mobile Japanese antiaircraft weapon in common use. As originally designed, it was not satisfactory, and was subsequently redesigned. It had a pedestal mount, horizontal sliding breechblock, and a hydropneumatic recoil system. In firing position the wheels are detached and the gun rests on six outriggers. Thirty to 45 minutes were required to prepare the gun for action. The fuze setter was continuous and automatic.

System name Type-14 105mm Anti-Aircraft Artillery
Caliber105-mm (4.13 inch).
Maximum range: Vertical36,000 feet.
Maximum range: Horizontal20,000 yards.
Maximum elevation+85°.
Maximum depression0°.
Traverse360°.
Weight in firing position7 tons.
Muzzle velocity2,300 feet per second.
Ammunition High explosive
