| Specifications
|
|---|
| Country Of Origin: | UK |
| Designation: | Armoured Scout Car |
| Configuration: | 4 x 4 |
| Manufacturer: | Daimler Limited, Coventry, England |
| Crew: | 2 |
| Armament: | 1 x 7.62 mm MG, 2 x 3 smoke grenade dischargers |
| Ammunition: | 1,000 x 7.62 mm |
| Length: | 3.835 m |
| Width: | 1.905 m |
| Height: | 1.879 m |
| Ground Clearance: | 0.33 m |
| Wheelbase: | 2.286 m |
| Weight (Combat): | 4,400 kg |
| Weight (Empty): | 3,640 kg |
| Power To Weight Ratio: | 29.35 bhp / tonne |
| Engine: | Rolls-Royce B60 Mk 6A 6-cylinder in-line water-cooled gasoline engine, 129 bhp at 3,750 rpm |
| Maximum Road Speed: | 93 km / hr |
| Maximum Range: | 306 km |
| Fuel Capacity: | 96 lit |
| Fording: | 0.914 m |
| Fording With Preparation: | 1.524 m |
| Vertical Obstacle: | 0.406 m |
| Trench With Channels: | 1.22 m |
| Gradient: | 46 % |
| Side Slope: | 30 % |
| Armour: | 8-16 mm (maximum) |
| Armour Type: | Steel |
| NBC System: | None |
| Night Vision: | None |
