1. To ensure that the 25-mm /COAX laser transmitter is properly seated:

a. Straddle the 25-mm barrel with your back to the turret.
b. Grasp the laser transmitter like a football center grasps the ball.
c. Using both hands, quickly and firmly "hike" the transmitter to the rear, without letting go.

2. Clean the laser transmitter lenses with alcohol pads; dust with a clean, dry, soft cloth.

3. Ensure that you use one flat washer and one lock washer on each bolt when securing the TOW laser transmitter to the TOW launcher.
