| Specifications
|
|---|
|
Alternative Designations |
BTR-60-PK |
|
Date of Introduction |
1963 |
|
Proliferation |
At least 30 countries (including variants) |
|
Description |
|
|
Crew |
2 |
|
Troop Capacity |
12 |
|
Combat Weight (mt) |
10.1 |
|
Chassis Length Overall (m) |
7.22 |
|
Height Overall (m) |
2.06 |
|
Width Overall (m) |
2.82 |
|
Ground Pressure (kg/cm 2 ) |
INA |
|
Drive Formula |
8 x 8 |
|
Automotive Performance |
|
|
Engine Type |
2 x 180-hp Gasoline |
|
Cruising Range (km) |
500 |
|
Speed (km/h) |
|
|
Max Road |
80 |
|
Max Off-Road |
60 |
|
Average Cross-Country |
INA |
|
Max Swim |
10 |
|
Fording Depths (m) |
Amphibious |
|
Radio |
INA |
|
Protection |
|
|
Armor, Turret Front (mm) |
7-9mm hull front (no turret) |
|
Applique Armor (mm) |
N/A |
|
Explosive Reactive Armor (mm) |
N/A |
|
Active Protective System |
N/A |
|
Mineclearing Equipment |
N/A |
|
Self-Entrenching Blade |
N/A |
|
NBC Protection System |
Collective |
|
Smoke Equipment |
N/A |
|
ARMAMENT |
|
|
Main Armament |
|
|
Caliber, Type, Name |
12.7-mm (12.7 x 108) heavy MG, DShK |
|
Rate of Fire (rd/min) |
80-100 (practical) |
|
Loader Type |
Belt feed |
|
Ready/Stowed Rounds |
INA |
|
Elevation (°) |
-10/+80 |
|
Fire on Move |
Yes |
|
Auxiliary Weapons |
|
|
Caliber, Type, Name |
2 x 7.62-mm machinegun PKT |
|
Mount Type |
Vehicle top |
|
Maximum Aimed Range (m) |
1,500 |
|
Max Effective Range (m) |
|
|
Day |
1,000 |
|
Night |
N/A |
|
Fire on Move |
Yes |
|
Rate of Fire (rd/min) |
250 practical / 650 cyclic, in 2-10 rd bursts |
|
ATGM Launcher |
N/A |
|
Firing Ports |
3 on each side |
|
FIRE CONTROL |
|
FCS Name |
N/A |
|
Main Gun Stabilization |
N/A |
|
Rangefinder |
N/A |
|
Infrared Searchlight |
N/A |
|
Sights w/Magnification |
|
|
Gunner |
|
|
Day |
K10-T |
|
Field of View (°) |
INA |
|
Acquisition Range (m) |
1,500 (est) |
|
Night |
N/A |
|
Commander Fire Main Gun |
No |
