| Specifications
|
|---|
|
Alternative Designations |
GAZ 41-08 |
|
Date of Introduction |
1963 |
|
Proliferation |
At least 45 countries |
|
Description |
|
|
Crew |
4 |
|
Troop Capacity |
0 (for this configuration) |
|
Combat Weight (mt) |
7.0 |
|
Chassis Length Overall (m) |
5.75 |
|
Height Overall (m) |
2.31 |
|
Width Overall (m) |
2.75 |
|
Ground Pressure (kg/cm 2 ) |
INA |
|
Drive Formula |
4 x 4 (+ 4 auxiliary wheels) |
|
Automotive Performance |
|
|
Engine Type |
140-hp Gasoline |
|
Cruising Range (km) |
750 |
|
Max Road Speed (km/h) |
95 |
|
Max Off-Road |
INA |
|
Average Cross-Country |
INA |
|
Max Swim |
10 |
|
Fording Depths (m) |
Amphibious |
|
Radio |
R-123 |
|
Protection |
|
|
Armor, Turret Front (mm) |
10 |
|
Applique Armor (mm) |
N/A |
|
Explosive Reactive Armor (mm) |
N/A |
|
Mineclearing Equipment |
N/A |
|
Self-Entrenching Blade |
N/A |
|
Active Protective System |
N/A |
|
NBC Protection System |
Collective |
|
Smoke Equipment |
N/A |
|
ARMAMENT |
|
|
Main Armament |
|
|
Caliber, Type, Name |
14.5-mm Machinegun KPVT |
|
Rate of Fire (rd/min) |
150 practical/600 cyclic |
|
Loader Type |
Belt feed |
|
Ready/Stowed Rounds |
500/0 |
|
Elevation (°) |
-5 / +30 |
|
Fire on Move |
Yes |
|
Auxiliary Weapon |
|
|
Caliber, Type, Name |
7.62-mm (7.62x 54R) Machinegun PKT |
|
Mount Type |
Coax |
|
Maximum Aimed Range (m) |
1,500 |
|
Max Effective Range (m) |
|
|
Day |
1,000m / 400-500 on the move |
|
Night |
N/A |
|
Fire on Move |
Yes |
|
Rate of Fire (rd/min) |
250 practical / 650 cyclic in 2-10 round bursts |
|
ATGM Launcher |
N/A |
|
Firing Ports |
INA |
|
FIRE CONTROL |
|
|
FCS Name |
N/A |
|
Main Gun Stabilization |
N/A |
|
Rangefinder |
N/A |
|
Infrared Searchlight |
INA |
|
Sights w/Magnification |
|
|
Gunner |
|
|
Day |
PP-61AM |
|
Field of View (°) |
23 |
|
Acquisition Range (m) |
2,000 |
|
Night |
N/A |
|
Field of View (°) |
INA |
|
Acquisition Range (m) |
INA |
|
Commander Fire Main Gun |
No |
|
MAIN ARMAMENT AMMUNITION |
|
|
Caliber, Type, Name |
|
|
14.5-mm API-T |
|
|
Maximum Aimed Range (m) |
INA |
|
Max Effective Range (m) |
|
|
Day |
2,000 |
|
Night |
INA |
|
Tactical AA Range |
1,400 |
|
Armor Penetration (mm) |
20 at 1,000 m/30 at 500 m |
|
Other Ammunition Types |
14.5-mm API, I-T, HE-T Type MDZ
|
