Alpino class Frigates

The Alpino class were a pair of Anti-submarine frigates built for the Italian Navy during the Cold War. Originally named Circe, along with sister ship Carabiniere, Alpino constituted a class of only two units, since the other two planned: Perseo and Polluce were removed from the program. By the early 1990s ALPIN0 was performing duty as a Mine-Hunter Support and Command ship [mine hunter mothership], and CARABINLERE was performing duty as an experimental ship. Originally conceived as a follow-on to the Alpino-class and taking the place of the two cancelled units, the Lupo class emerged as rather different design.

The design was originally conceived as an enlarged version of the Canopo class frigates. The design was however changed radically with a CODOG machinery suite comprising gas turbines and diesels. These ships introduced the use of ship based helicopters and variable depth sonar into the Italian Navy. The ships underwent significant modernisation in the 1980s with the fitting of new sonar and electronic warfare equipment.

Initially four ships were planned to be ordered in 1959 to 1961. These ships were to be named Circe, Climene, Perseo and Polluce in honor of the Second World War-era Spica class torpedo boats of those names. These ships were postponed while the designs were updated and two ships were ordered in 1962. Both vessels were built by CNR in Riva Trigoso and named after types of soldiers and specifically after two Second World War-era Soldati class destroyers.

Italy's 1973 sale of four Alpino-class destroyer escorts to Peru broke the UK's virtual monopoly on the supply of newly built major surface warships. The desire of some of the Latin American countries to upgrade and modernize their inventories is best reflected in the types of equipment acquired. Purchases include some of the more sophisticated materiel currently available on the world market. This is especially evident in the acquisitions of major naval warships. Latin American countries view themselves as modern nation states and have actively sought arms reflectin!~ this status. This has been and will remain the prime motivating factors behind their acquisition of sophisticated weapons.

#Name builderLaid DownLaunchCompleteDecomm
F580Alpino
[ex-Circe]
Cantieri Navali del
Tirreno di
Riva Trigoso
08 Feb 1963
27 Feb 1963
10 June 1967
14 Jun 1967
14 Jan 196831 Mar 2006
F581CarabiniereCantieri Navali del
Tirreno di
Riva Trigoso
09 Jan 196530 Sep 196728 Apr 1968
...Perseo............cancelled
originally
four unts
planned
...Polluce............cancelled
originally
four unts
planned

Displacement 2,400 t standard
2,550 t normal load
2,689 t full load
Length 113.30 (o.a.) mt. / 368 ft
Width 13.30 mt.
Draft 3.80 mt.
Machinery CODAG; (combining gas turbines and diesels)
two Tosi-Metrovick G 6 gas turbines 15,000 shp;
four Tosi QTV 320-12 diesel engines 16,800 shp;
two shafts.
Speed 24 kn with diesels only
29 knots with gas turbines
28 knots
Fuel270 tonnes of naphtha
Autonomy4,000 miles at 18 knots
Armament
  • 6 x 75/62 mm OTO Melara guns
    (3 on CARABINIERE)
  • 11 WHITEHEAD KI 13 depth-charge launcher
    (only ALPINO)
  • 2 x 324 mm MK32 triple torpcdo launchers
  • 2 x 105 mm rockct launchers
  • Electronics Radar
  • SPS-12
  • SPS-2 RTN-30X
  • RTN-10X
    Sonar
  • SQS-43
  • SQA-10
    Electronic warfare
  • SLR-4 ESM system
  • SLQ-D ECM system
  • 2× SCLAR decoy launchers
  • Aviation 1 AB-212 ASW helicopter
    Crew264
    247 (19 officers)
