C-4
| Specifications | |
|---|---|
| Variants |
G-159 - the first production version G-159C - stretched fuselage, seating for 37 TC-4C - USMC trainer for A-6 for , based on G-159C VC-4A - VIP transport based on G-159 |
| Wingspan | 23.9 m / 78 ft |
| Length | 19.4 m / 67 ft 11 in [G-159 / VC-4A] |
| Height | 6.8 m / 22 ft 4 in |
| Wing area | 56.7 sq. m |
| Empty weight | 9930 kg / 22,070-24,575 lbs |
| Takeoff weight | 15920 kg / 36,000 lbs |
| Engines | 2xRolls-Royce "Dart" Mk.529, 2078 hp each |
| Maximum speed | 350 mph / 375 knots |
| Cruise speed | 575 km/h at 7625 m |
| Landing speed | 135 km/h |
| Climb rate | 9.7 m/s |
| Ceiling | 10670 m / 35,570 ft |
| Takeoff roll | 635 m |
| Landing roll | 460 m |
| Range | 3780 km / 2240 miles |
| Crew | 2 |
| Payload | 10-24 passengers |
|
