C-4

Specifications
Variants G-159 - the first production version
G-159C - stretched fuselage, seating for 37
TC-4C - USMC trainer for A-6 for , based on G-159C
VC-4A - VIP transport based on G-159
Wingspan 23.9 m / 78 ft
Length19.4 m / 67 ft 11 in [G-159 / VC-4A]
Height 6.8 m / 22 ft 4 in
Wing area 56.7 sq. m
Empty weight 9930 kg / 22,070-24,575 lbs
Takeoff weight 15920 kg / 36,000 lbs
Engines 2xRolls-Royce "Dart" Mk.529, 2078 hp each
Maximum speed350 mph / 375 knots
Cruise speed 575 km/h at 7625 m
Landing speed 135 km/h
Climb rate 9.7 m/s
Ceiling 10670 m / 35,570 ft
Takeoff roll 635 m
Landing roll 460 m
Range 3780 km / 2240 miles
Crew2
Payload 10-24 passengers
