Modernized BMD-4M (Boyevaya Mashina Desanta)

Armament
  • 100-mm gun 2A70 (34 high-explosive projectile)
  • 30-mm automatic gun 2A72 (500 rounds)
  • coaxial 7.62 mm PKT (2000 rounds)
  • ATGM "Arkan" (4 controlled shot)
    • Mass 13500 kg
    Engine Type and Model multi-fuel diesel, V10, with the angle of 144 ° UTD-29
    Specific power37 hp / t
    Engine power 500 (367 KW)hp
    Suspension independent, torsion bar with telescopic hydraulic shock absorbers
    Length 6100 mm
    Width 3110
    Height , 2450 mm
    Crew 2 + 6 people

    BMD-4M (Boyevaya Mashina Desanta)
