| Specifications
|
|---|
|
Alternative Designations | 9A52-2 Smerch-M |
|
Date of Introduction | 1987 |
|
Proliferation | At least 4 countries |
|
Description | |
|
Crew | 4 (7 with 9K58 Complex) |
|
Chassis/Carriage | MAZ-543M 8x8 wheeled |
|
Combat Weight (mt) | 43.7 |
|
Chassis Length Overall (m) | 12.1 |
|
Height Overall (m) | 3.05 |
|
Width Overall (m) | 3.05 |
|
Automotive Performance | |
|
Engine Type | 518 hp, V-12 diesel engine |
|
Cruising Range (km) | 850 km |
|
Speed (km/h) | |
|
Max Road | 60 |
|
Max Off-Road | 35 |
|
Cross-Country | INA |
|
Max Swim | N/A |
|
Fording Depths (m) Unprepared | 1.1 |
|
Emplacement Time (min) | 3 |
|
Displacement Time (min) | 3 |
|
Radio | R-123M |
|
Protection | |
|
Armor, Front (mm) | None |
|
Armor Side (mm) | None |
|
Armor Roof (mm) | None |
|
Self-Entrenching Blade | No |
|
NBC Protection System | No |
|
Smoke Equipment | No |
|
ARMAMENT | |
|
Launcher | |
|
Caliber, Type, Name | 300-mm, 9A52 |
|
Number of Tubes | 12 (3 rows of 4 tubes) |
|
Launch Rate | |
|
Full Salvo Time | 12 rounds in 38 seconds |
|
Single Rocket Interval | 3 seconds per rocket |
|
Loader Type | Manual |
|
Reload Time | 36 minutes |
|
Launcher Drive | Electric |
|
Traverse | (°) |
|
Left | 30 |
|
Right | 30 |
|
Total | 60 |
|
Elevation (°) (-/+) | -0/+55° |
|
FIRE CONTROL | |
|
Indirect Fire | PG-1M Panoramic Telescope (PANTEL) |
|
Collimator | K-1 |
|
Fire Control Computer | None |
|
Position Location System | None |
|
MAIN ARMAMENT AMMUNITION | |
|
Caliber, Type, Name | |
|
300-mm Frag-HE, 9M55F | |
|
Indirect Fire Range (m) | |
|
Minimum Range | 20,000 |
|
Maximum Range | 90,000 |
|
Warhead Weight (kg) | 258 |
|
Rocket Length (m) | 7.6 |
|
Maximum Velocity | INA |
|
Fuze Type | Electronic timing (ET) |
|
300-mm DPICM, 9M55K | |
|
Indirect Fire Range (m) | |
|
Minimum Range | 20,000 |
|
Maximum Range | 70,000 |
|
Warhead Weight (kg) | 235 |
|
Rocket Length (m) | 7.6 |
|
Maximum Velocity | INA |
|
Fuze Type | Electronic timing (ET) |
|
300-mm Sensor-fuzed (MOTIV-3M), 9M55K1 | |
|
Indirect Fire Range (m) | |
|
Minimum Range | 20,000 |
|
Maximum Range | 70,000 |
|
Warhead Weight (kg) | 233 |
|
Rocket Length (m) | 7.6 |
|
Maximum Velocity | INA |
|
Fuze Type | Electronic timing (ET) |
|
Other Ammunition Types | Smoke, Incendiary, Chemical, Leaflet,
Fuel Air Explosive (FAE), R-90 expendable miniature UAV (experi-mental)
|
