| Specifications
|
|---|
|
Alternative Designations |
MT-LB-T |
|
Date of Introduction |
1970, modernized in 1995 |
|
Proliferation |
At least 9 countries |
|
Description |
|
|
Crew |
2 |
|
Troop Capacity |
11 passengers |
|
Combat Weight (mt) |
11.9 |
|
Chassis Length Overall (m) |
6.35 |
|
Height Overall (m) |
1.87 |
|
Width Overall (m) |
2.85 |
|
Ground Pressure (kg/cm 2 ) |
0.46 standard track / 0.28 wide track |
|
Automotive Performance |
|
|
Engine Type |
290-hp Diesel |
|
Cruising Range (km) |
500 |
|
Speed (km/h) |
|
|
Max Road |
61.5/70 modernized |
|
Max Off-Road |
30/45 modernized |
|
Average Cross-Country |
INA |
|
Max Swim |
3-4 |
|
Fording Depth (m) |
Amphibious |
|
Radio |
R-123 or upgrade to -123M/-173 |
|
Protection |
|
|
Armor, Turret Front (mm) |
7-14 |
|
Applique Armor (mm) |
N/A |
|
Explosive Reactive Armor (mm) |
INA |
|
Active Protective System |
N/A |
|
Mineclearing Equipment |
N/A |
|
Self-Entrenching Blade |
Yes |
|
NBC Protection System |
Collective |
|
Smoke Equipment |
N/A |
|
ARMAMENT |
|
|
Main Armament(s) |
|
|
Caliber, Type, Name |
7.62-mm (7.62x 54R) machinegun, PKT |
|
Rate of Fire (rd/min) |
250 practical / 650 cyclic, 2-10 round bursts |
|
Loader Type |
Belt-feed |
|
Ready/Stowed Rounds |
INA |
|
Elevation (°) |
-5/ +35 |
|
Fire on Move |
Yes |
|
Auxiliary Weapon |
N/A |
|
ATGM Launcher |
N/A |
|
Firing Ports |
1 on each side and 1 in each rear door. |
|
FIRE CONTROL |
|
|
FCS Name |
INA |
|
Main Gun Stabilization |
N/A |
|
Rangefinder |
N/A |
|
Infrared Searchlight |
N/A |
|
Sights w/Magnification |
|
|
Gunner |
|
|
Day |
PP-61AM, 2.6x |
|
Field of View (°) |
23 |
|
Acquisition Range (m) |
1,500 (est) |
|
Night |
N/A |
|
Commander Fire Main Gun |
No
|
|
MAIN ARMAMENT AMMUNITION |
|
|
Caliber, Type, Name |
7.62-mm API, API-T |
|
Maximum Aimed Range (m) |
1,500 |
|
Max Effective Range (m) |
|
|
Day |
1,000/400-500 on the move |
|
Night |
INA |
|
Tactical AA Range |
INA |
|
Armor Penetration (mm) |
8 (RHA) at 500 m |
|
Other Ammunition Types |
Light Ball, Ball-T, Heavy Ball,
Incendiary
|
