XM1095 MTV Trailer (MTVT)
The XM1095 MTV Trailer (MTVT) is designed to be towed by the MTV family of vehicles. The M1095 is a dual axle trailer with a gross payload capacity of 10,000 pounds. The trailer is equipped with an air brake system actuated by the prime mover and a parking brake system to prevent movement of the trailer when not connected to the prime mover. A canvas and bows kit is provided to protect the cargo from the elements.
| xxx |
MTVTrailer (M1095) |
 |
|||
 |
xxx | ||||
| xxx | |||||
 |
x |
Dimensions |
|||
| Length | Overall | 229.5" (5,829 mm) | |||
| Cargo Bed (inside) | 168.8" (4,288 mm) | ||||
| Height | Overall | 80.8" (2,052 mm) | |||
| Deck Heighth | Empty | 62.3" (1,582 mm) | |||
| Loaded | 60.0" (1,524 mm) | ||||
| Width | Overall (outside) | 96" (2,438 mm) | |||
| Cargo Bed (inside) | 90.8" (2,306 mm) | ||||
| Vehicle Curb Weight | (VCW) | 9,200 lb (4,173 kg) | |||
| Gross Curb Weight | (GVW) | 19,200 lb (8,709 kg) | |||
| Tongue Weight | at VCW | 800 lb (363 kg) | |||
| at GVW | 1,924 lb (873 kg) | ||||
| Ground Clearance | Loaded | 12.3" (312 mm) | |||
| Empty | 14.8" (376 mm) | ||||
| x |
Performance Characteristics |
||||
| Maximum Grade | 60% | ||||
| Slide Slope | 30% | ||||
| Fording | 60" (1,524 mm) | ||||
| Maximum Payload | 10,000 lb (4,536 kg) | ||||
| x |
Equipment Specifications |
||||
| Axle | Rockwell | Dual | |||
| Brakes | Wedge pneumatic | ||||
| Antilock System | Yes | ||||
| Cargo Bed | Construction | All-steel, E-coat rustproofing dropside with side rail storage | |||
| Ladder | Stowed, metallic | ||||
| Tie Down Points | Yes | ||||
| Standard Option | Bows and tarp kit | ||||
| Electric System | 12/24 Volt with blackout | ||||
| Tires | 395/80R20 | ||||
| Integral Sling Bar | Slung under CH-47 and CH-53 | ||||
| Suspension | High travel dual axle parabolic taper leaf spring bogie with anti-sway bar | ||||
